Power Units Capabilities
Livingston & Haven's System Group designs, manufactures and installs integrated power units, lubrication systems and process pumping packages for a multitude of industrial applications and original equipment manufacturers (OEMs). As an innovative problem-solver, the Hydraulic Systems Group constantly explores new technologies, providing customers with unique solutions to their fluid power requirements.
|
Capabilities
|
Documentation
- To any level required
- AutoCAD 2000 and AutoCAD LT2000
Shop Capability
- 12,200 sq. ft. fabrication area
- 10 hydraulic fabrication technicians
- 6 ton overhead crane
- EPA compliant paint booth
Testing
- Testing in house of up to 300 HP, 460 volt ,60 hz, electric motors
- 1000 gallons of hydraulic test oil on site
- Test single pump flows up to 300 gpm
Reservoirs
- 3 gallon to 3000 gallon - any shape, style, or size
- Steel or Stainless Steel - all grades
- Monitoring devices - Standard and Special
Welding
- Meets ASME Article IX and V as required
- Meets ASME 31.3B Process Piping as required
- Meets AWS D1.1 General Shop Practice
- Can weld to all X-ray and NDE requirements
|
Horsepower
- ¼ HP - 1200 HP and up
- All frame types
- All voltages or frequencies
- All brands
Pipe
- ¼" - 12" any schedule
- Threaded, butt-weld, socket-weld
- Steel or stainless steel - all grades
- Imperial or metric
- See welding for qualifications
Tubing
- ¼" - 2" any wall thickness
- Flare, bite type, Seal Lok, and others
- Imperial or metric
Electrical
- We fabricate control panels and integrate control packages with hydraulics and pneumatics
- To NEC & NEMA
- To any customer specific requirement
- Rigid, EMT, Flexible, or SO conduit
- All classes of explosion proof
Painting
- Blasting and cleaning to all SSPC levels, 1-10
- Industrial enamel, polyurethane, and epoxy - All brands
|
|
We Can Comply to the following Standards or Specifications:
|
- ASME
- ANSI
- JIC
- SAE
- NFPA
- API
- NEC
|
- ISO
- AWS
- SSPC
- ASTM
- OSHA
- CSA
- NEMA
|
|
|
|
- Certified Fluid Power Specialists as Designers and Project Managers
- Field Installation and Start Up Assistance Available
- Ability to Build Units for Overseas Shipments - Currently Have Supplied Units to China, South Africa, Mexico, Venezuela, Canada, Australia, Brazil, Trinidad, Congo, and others
|
|
|
|
